RRD crankshaft reinforced 42.1mm long stroke and 85mm long rod Peugeot 103 sp, mv, mvl, lm, vogue ... electronic cone

This RRD COMPETITION crankshaft is a long stroke model, the only electronic cone to be released for Peugeot 103, 85mm long connecting rod version (+ 9mm) to improve performance and reduce the forcing on the piston, the stroke represents the stroke of the piston, if we offset the crank pin by 1.5mm this offers 3mm of additional travel, as an example:



Ø46mm kit in 39.1mm stroke (original) = real 64.98cc

Ø46mm kit in 42.1mm RRD stroke (this crankshaft) = real 69.96cc

PARMAKIT Ø50mm kit in 39.1mm stroke (original) = 76.77cc real

PARMAKIT Ø50mm kit 42.1mm RRD stroke (this crankshaft) = real 82.66cc





This crankshaft therefore offers additional cubic centimeters of displacement, an enormous gain in torque, while bringing you closer to the so-called "square" engine with your large kits! This model is intended for large kits. The connecting rod has therefore been increased + 9mm to improve the motor movement, reduce the forcing on the piston and free the turns. This crankshaft is cut in the best special case-hardened steels and has undergone 3 treatments, case-hardening.



This very high quality crankshaft has been fully studied, designed and tested in our workshops. It is made of high-end materials in Europe. This crankshaft offers many advantages:



-Course increased to 42.1mm instead of 39.1mm, which offers an increase in displacement, the race also makes it possible to approach again the square race (46X42.1) and to have a better behavior engine in relation to a base race 39.1.



-Specific crankshaft balancing for the average piston weights of large kits, calculated on an average MALOSSI / POLINI / AIRSAL ...



- Ultra reinforced connecting rod placed on a 16mm diameter crank pin, ultra reinforced head and foot cage, improved head lubrication. Length 85mm (+ 9mm) to improve performance, release the turns, improve engine movement, reduce the forcing on the piston, raise the level of the piston at PMB which avoids striking problems.



-On certain housings, it may be necessary to mill lightly or to pass a blow of abrasive roller type DREMEL for the passage of the small end. A distance of 0.5mm is required between the crankcase and the big end as a precaution.



* Mandatory milling on MALOSSI housings (band to pass the head)

* Mandatory milling on POLINI housings (band to pass the head)

-Price has been lowered for small, limited quantities, with very high quality of materials and workmanship!



-Cage of connecting rods in 12X16X16mm



The increase in stroke of 3mm as well as the increased connecting rod + 9mm, will require you to use a base shim of about 10mm), we sell the 10mm shims with a form of base type origin, to align with your transfers engines. Next, play with your base gaskets to obtain the desired compression ratio (also to be defined according to your diagrams). The PMB piston goes down an additional 1.5mm, ideally you will align your lights to the PMB. Attention, do not use this crankshaft with a kit already prepared with very large diagrams on a normal race, the diagrams would end up being too high ... We recommend at most, diagrams of 196 / 133. Attention, check that the piston closes the exhaust port by at least 0.5mm at top dead center (TDC). On some kits, it is possible that the piston does not close the light. It will not adapt over a long run! Originally, the ignition of the electronic 103 is set at 0.9mm before TDC. You can put 1.1mm to 1.2mm ahead of this long stroke (on a normal stroke, you can go up to 1.3 to 1.4mm before TDC).



Attention for the Ø50mm PARMAKIT kit you have to change the piston and start for example on the top performance Ø50mm TPR (also exists in ITALKIT for TPR AM6 50mm kit) because the exhaust port is not blocked at top dead center. In addition, the cylinder head must be reworked to respect the angle of the piston head, etc ...



Compression Ratio : Once you have aligned your cylinder to PMB and with proper diagrams ... Machine your cylinder head to have a nice compression ratio. On air cooled engine, we recommend a squish of 1.00mm with a compression ratio of 12 to 12.6: 1 MAXIMUM. On liquid cooled engine with pump, a 0.6mm squish can be used with a compression ratio of 14 to 14.5: 1. On a 50mm diameter air cooled parmakit with our long stroke, we will recommend a chamber volume included. between 7.5ml and 7.2mm. On a Ø46mm kit, we recommend instead between 6.3ml and 6.08ml for air cooling or between 5.38ml and 5.18ml for liquid cooling!



* With this crankshaft and its 10mm base shim, used 125mm M7 elongated studs only!
